Enjoy a panoramic view of your gaming PC without compromising on airflow, with the APNX V1 PC Case. This innovative chassis features an angled front intake, which channels the air through the case more efficiently than a traditional side intake. Utilising a dual chamber design, the APNX V1 showcases all your prized gaming hardware, whilst concealing excess cable length. With its sleek, modern aesthetics and elegant wood panelling, this PC case will be a statement piece in your gaming set-up.

APNX V1 PC Case at a Glance:

  • Dual-chamber mid-tower PC case with panoramic tempered glass panelling
  • Angled front intake for optimised airflow
  • Adjustable motherboard positioning
  • Supports up to ten fans and liquid cooling
  • Easy cable management and quick-release brackets and panels
  • Available in three colours with wood panelling accent


Performance with Personality

The APNX V1 PC case is more than just form meeting function. The sleek, modern aesthetics are influenced by the innovations made to enhance cooling within this panoramic chassis. The angled front intake creates a bold shape, while promoting more natural airflow throughout the case. Its path is even mirrored on the top panel ventilation, showing how the air enters and exits. This is paired with fully tempered glass panelling on the front and side, offering an uninterrupted view of your prized gaming hardware within.

This is the black edition, with a sleek matte finish that is sure to look good in any set-up. What’s more, this edition features wood panelling on the angled front intake. Choose between solid walnut or ash wood, for a touch of sophistication and elegance.


Upgraded Thermals

In addition to the innovative angled front intake, the APNX V1 has extensive support for cooling hardware. The angled front, top, bottom, and rear can all support fans or radiators, with all but the rear featuring quick-release brackets for easy installation. In total, you can support up to ten fans with liquid cooling hardware, too.

The front intake can accommodate three 120mm, two 140mm, or two 160mm fans and radiators up to 360mm long. Both the top and bottom bracket can support three 120mm or two 140mm fans and a radiator up to 360mm long, but it is not recommended to install a radiator on the bottom due to the motherboard potentially limiting space. Upon the rear, you can install either a 120mm fan or radiator. What’s more, there is 170mm clearance for CPU coolers.


Innovative Layout

The APNX V1 front chamber has been optimised to support a wide range of gaming hardware. The motherboard tray can accommodate boards up to the ATX form factor, and there are seven expansion slots on the rear panel for PCIe devices. In addition to this, you can mount your motherboard in one of two positions, depending on if you want to enhance airflow for your GPU or CPU. The lower position provides more space for cooling hardware at the top, allowing for thicker radiators and creating better airflow for the CPU. Alternatively, the higher position provides more even spacing at the top and bottom, which enhances cooling performance from the bottom while leaving ample room for radiators at the top.

To cover any gaps your motherboard position may create, a branded APNX bracket can be installed on the rear panel.

What’s more, the APNX V1 PC case includes an adjustable GPU mount. This can be configured by height and swivel, providing excellent support for even the heaviest graphics cards up to 395mm long.

Rear Chamber

As a dual-chamber chassis, there is a rear compartment designed to hide away any messy cable runs. This space is 90mm deep and provides clear channels and fasteners for your wiring. There is a dedicated shelf for the PSU, accommodating ATX models up to 220mm long. Below this, there is a removable, hinged storage bracket, facilitating easy access and installation. It can support either up to two 3.5” and four 2.5” drives or up to six 2.5” drives.

The I/O panel sits on the angled front intake, but the cables feed into the rear chamber. This features one USB3.2 Gen 2x2 Type-C, two USB 3.2 Type A ports, and an audio/microphone combined 3.5mm jack.


Hassle-Free Maintenance

The APNX V1 has been designed for ease of use. All quick-release brackets feature minimal screws for a smoother installation process. On top of this, the top, angled front, and both side panels are screwless. They snap and lock effortlessly into place, so you can upgrade your hardware without hassle. Please note, the screws included on the side panels are provided for security in transit. They will not need screwing back in unless you plan to move the PC case.

What’s more, there are a number of removable filters across the chassis, simplifying the cleaning and maintenance process.

Colour
Primary Colour Black
Materials
Materials Plastic, Steel, Tempered Glass, Wood
Case
Case Type Mid Tower
Drive Bays
2.5 inch internal drive bay 6
3.5 inch internal drive bay 2
Motherboard Support
Compatible motherboard formats ATX, Micro-ATX, Mini-ITX
Max. Motherboard Format ATX
Radiator Support
Max. Radiator Compatibility 1x Single (120 mm), 3x Triple (360 mm)
Additional Contents
Included fans 2x 120 mm
Lighting
Lighting No
Internal Dimensions
Max. CPU Cooler Height 170 mm
Max. GPU Length 395 mm
Max. PSU Length / Depth 220 mm
Case Features
I/O position Top
Side panel with window
Cable Management Yes
Filters included Yes
Power Supply
PSU included No
PSU Format ATX
Power Supply Position rear side / top
Dimensions
Length / Depth 500 mm
Width 290 mm
Height 485.5 mm
Expansion Slots
Expansion slots / PCI slots 7
External Ports
USB4 Gen 2x2 (external) Type C 1
USB 3.0 (external) Type A 2
Audio outputs & inputs 1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
Card reader No
Fan Support
120 mm fans 10
140 mm fans 6
160 mm fans 2
